Chi-Fi
Excellence
1 Year of
Warranty
Ideal for
Audiophiles
Best Suited for
Portable Use
Bluetooth with
LDAC, aptX HD
Upto 10 Hours of
Battery Life
2.5mm & 4.4mm
Balanced Output
ESS Sabre ES9038PRO
Dual DAC Chip
Upto 3W @ 32Ω
Power Output
Upto 2TB
of Storage
Battery Capacity of
9200 mAh
Volume
Controls
DESCRIPTION
EMBEDDED WITH FLAGSHIP-GRADE DUAL ES9038PRO DAC CHIPS FOR PRISTINE AUDIO
Meet the latest flagship Android music player from FiiO, the M17. Featuring a top of the line ES9038Pro Dual DAC chipset, the M17 provides you with impeccable high-resolution audio decoding performance. It is a 32-Bit premium Sabre DAC that delivers excellent high-resolution audio signal decoding with low distortion and high SNR ratings with decoding support for PCM, DSD and MQA formats natively. FiiO M17 is designed for audio enthusiasts who give utmost attention to every single detail from their music.



FEATURING THX-AAA 788+ AMPLIFICATION ARCHITECTURE FOR DESKTOP-GRADE POWER
FiiO partnered with the renowned brand THX to elevate the amplification power for M17. THX is a well-recognised amplifier architecture brand and they have designed and equipped the FiiO M17 with desktop-grade THX-AAA 788+ amplifier architecture which produces a tremendously powerful output with lower distortion and clean background. The M17 is capable of providing up to 3W of power when connected via a DC power supply. On the battery, this output power is controlled for better battery life.




BLAZING FAST PERFORMANCE WITH SNAPDRAGON SOC AND ANDROID 10 OPERATING SYSTEM
FiiO M17 houses Qualcomm’s latest Snapdragon 660 SoC chip. This is an eight-core high-performance CPU chip that delivers lightning-fast performance with applications. It also has 4GB of ram that allows for using multiple applications at once. Want to use your favourite media application on the go? The FiiO M17 is loaded with the latest Android 10 OS that provides you with the widest range of media and music applications available with the Google Play store.

EMBEDDED WITH THE FLAGSHIP QCC5124 CHIP AND XMOS CHIP FOR HD BLUETOOTH OPERATION
The FiiO M17 has been equipped with the latest flagship grade QCC5124 chip to offer Bluetooth 5.0 connectivity with support for SBC, AAC, aptX, aptX-HD, aptX-Adaptive and LDAC protocols. The M17 also features an XMOS receiver chip that works in conjunction with the QCC5124 chip to deliver ultra-low latency and support for PCM 32bit/768kHz and DSD512 formats. The FiiO M17 also supports MQA unfolding for master-level sound quality. With these technologies available, you can enjoy your music at the highest quality wirelessly.


MULTIPLE OUTPUT PORTS WITH POWERFUL DRIVING CAPACITY AND LINE-LEVEL OUTPUT PORTS
FiiO M17 offers an array of output ports to select. This is implemented in the design, so you do not need to worry about additional connectors and adapters for different devices. The FiiO M17 supports headphone output with 3.5mm and 6.35mm single-ended, as well as 2.5mm and 4.4mm balanced headphone output. The device also has separate single-ended and balanced line-out ports via independent 3.5mm and 4.4mm ports. M17 also features an RCA coaxial port that can act as input and output, depending on your requirement. The M17 is adjusted to provide a powerful output. The device has an output power rating of up to 3000mW per channel in Balanced out and a spectacular 16dB gain level in over-ear headphone mode.



OFFERING DESKTOP-GRADE GAIN CONTROL, POWER SUPPLY AND HEAT DISSIPATION CAPABILITY
The FiiO M17 offers four gain levels when used with battery power. You can toggle between Low, Medium, High and Headphone Mode. When operating in DC mode, super headphone mode gain is unlocked, with desktop-level amplification gain. To provide sufficient power the M17 has been equipped with two power supplies. You can use the M17 on battery power or choose to operate it in DC supply. With DC supply, the voltage is increased by 35% and offers superior performance. To keep the device temperature cool “H” Type heat dissipation and VC liquid cooling technologies are adopted. The M17’s 151g unibody aluminium alloy frame also effectively transfers heat out of the device.



CAREFULLY ENGINEERED WITH THE BEST COMPONENTS TO DELIVER SUPERIOR AUDIO PERFORMANCE
The FiiO M17’s design took 1.5 years to complete, going through various design iterations and internal structural design optimisation. The result is a device that makes excellent use of its space. Inside the M17 are carefully stacked analogue and digital boards with tantalum capacitors, ultra-low noise LDO architecture, NDK femtosecond crystal oscillator and gravity sensors. All these components add a solid foundation for smooth audio playback. The PCBs in the M17 is utilised with an immersion gold finish, with the analogue and digital sections physically separated by being on two different boards to reduce interference between the two portions. Seven high conductivity copper alloy shields also provide shielding to reduce internal and external electromagnetic interference.



COMES WITH A 5.99” FULL HD IPS DISPLAY AND A MASSIVE 9200mAH BATTERY CAPACITY
FiiO M17 is a highly equipped flagship device that boasts a 5.99” FHD+ display. It produces crisp, high-quality visuals with true to life colours. The 5.99” FHD+ display is more than enough to operate the device with ease. The M17 is embedded with a massive 9200mAH battery with 10 hours of battery life so you don’t run out of juice while listening to your music. The M17 can be operated via the battery mode which also offers quick charging with USB 3.0 or with the included DC12V power adaptor. It provides full performance with the DC power adapter connected.



SHOWCASING 7TH GENERATION MECH DESIGN WITH RGB LIGHTS AND DUAL VOLUME CONTROL
The futuristic, seamless, CNC- finished aluminium unibody design of the FiiO M17 evokes a sense of technological wonder. The mech-inspired sharp lines of the body, buttons and atmospheric lights give the M17 a bold and charismatic aura. The M17 features a seven-colour RGB ambient light system with extensive customisation options. Colours can be set to be either fixed, to follow the audio or to follow a cycle. The volume can be adjusted either using an analogue potentiometer knob or using buttons allowing you to quickly and easily go through 120 levels of volume through either method.


BUNDLED WITH AN ARRAY OF ACCESSORIES TO OFFER A PREMIUM EXPERIENCE
The team at FiiO have bundled the M17 with a variety of accessories to help you make the most of the M17. You will get an external adapter to charge the device, a cooling stand with a fan to keep the device cool, a PET screen protector with an oleophobic layer to protect your screen, a luxurious leather case to store your M17, a Micro-SD card ejector pin, an aluminium dust pin and a USB 3.0 data and power cable. The team at FiiO have included every piece of accessory that you could need to elevate the functioning of the M17.


SPECS
| MODEL | M17 |
| HARDWARE SOLUTION | Soc: Snapdragon 660, DAC: ES9038PRO*2, Amp: THX AAA-788+, Bluetooth: QCC5124, USB: XMOS XUF208, NDK Femtosecond crystal oscillator*2 |
| USER INTERFACE | Android/Pure Music/USB DAC/Bluetooth Receiver/AirPlay mode |
| COLOR | Black |
| SIZE | ≈156.4 * 88.5 * 28mm |
| WEIGHT | ≈610g |
| DISPLAY | 5.99 inches (1080*2160) incell fully fit screen |
| VOLUME CONTROL TYPE | Knob or button control |
| RAM | 4GB |
| ROM | 64GB/≈46GB |
| TF CARD | Single TF card slot, theoretically support up to 2TB |
| GAIN CONTROL | Low/medium/high/Over-ear headphone mode/Enhanced over-ear headphone mode (when connected to DC) |
| CHANNEL BALANCE | L20~R20(0.5dB/level) |
| RECOMMENDED HEADPHONE IMPEDANCE | 16~150Ω (SE output)/16~300Ω (BAL output) |
| BUTTONS | Physical button + analog potentiometer volume knob + HOLD lock switch + BAT/DC switch + touch screen |
| USB | Two-way TYPE C USB3.0(Charging/Data transmisson),USB HOST Type-C USB2.0 |
| PHONE OUTPUT | 3.5mm single-ended + 6.35mm single-ended + 2.5mm balanced + 4.4mm balanced |
| LINE OUT (LO) | 3.5mm port(shared PO) |
| COAX OUTPUT | RCA socket (coaxial decoding, coaxial output multiplexing) Coaxial decoding supports up to 192kHz-24bit/DSD64 Coaxial output supports up to 384kHz-24bit/DSD128 |
| BALANCED LINE OUT | 4.4mm port(shared 4.4mm balanced PO) |
| WIFI | 2.4GHz/5GHz,DLNA、AirPlay、WiFi music transfer |
| BLUETOOTH TRANSMITTER (5.0) | SBC/AAC/aptX/aptX HD/LDAC |
| BLUETOOTH RECEIVER (5.0) | SBC/AAC/aptX/aptX Low Latency/aptX HD/aptX Adaptive/LDAC |
| FiiO LINK | WiFi and Bluetooth control (Android), Bluetooth control (IOS) |
| MQA | MQA 8x unfold |
| ALL TO DSD | Yes |
| DOUBLE CLICK TO WAKEUP | Not supported, to be upgraded |
| IN-VEHICLE MODE | Would power on/off automatically when vehicle engine starts/stops |
| SAMPLING RATE | Local playback: Up to 384kHz-32bit/DSD256 USB DAC: Up to 768kHz-32bit/DSD512 |
| USB AUDIO | 384kHz-32bit/DSD256 (D2P/DOP) 768kHz-32bit/DSD512 (Native) |
| POWER-OFF TIMERS | Sleep/Idle poweroff |
| EQUALIZER | 10-band EQ (±12dB), 8 presets+custom preset, custom EQ supported |
| FIRMWARE UPGRADE | Supports via zip file + TF card + OTA |
| NAVIGATION CONTROL | Gesture control / 2-Bottom navigation / 3-Bottom navigation |
| POWER SUPPLY | Supports QC3.0, QC4.0 and PD2.0 and PD3.0 fast charge, POWER IN DC 12V |
| BATTERY CAPACITY | 9200mAh |
| CHARGING TIME | About 4.5h (QC fast charge) |
| STANDBY TIME | >1000h |
| 3.5MM HEADPHONE OUTPUT:>10H | |
| VOLUME | 76 |
| GAIN | L |
| SCREEN | Off |
| TEST FILE | MP3 44.1kHz/16bit |
| EQ | Off |
| LOAD | 32Ω |
| 2.5MM + 4.4MM BALANCED OUTPUT:>8H | |
| VOLUME | 65 |
| GAIN | L |
| SCREEN | Off |
| TEST FILE | MP3 44.1kHz/16bit |
| EQ | Off |
| LOAD | 32Ω |
| PO OUTPUT PARAMETERS (OVER-EAR HEADPHONE MODE) | |
| OUTPUT POWER | ≥740mW(16Ω / THD+N<1%) ≥500mW(32Ω /THD+N<1%) ≥63mW(300Ω / THD+N<1%) |
| NOISE FLOOR | ≤3.5μV(dbA) |
| FREQUENCY RESPONSE | 5Hz~80kHz(-3dB) |
| OUTPUT IMPEDANCE | ≤1Ω(32Ω) |
| CROSSTALK | ≥75dB(1kHz/32Ω) |
| THD+N | ≤0.0007%(1kHz/32Ω) |
| SNR | ≥120dB(dbA) |
| PEAK OUTPUT VOLTAGE | 11.3 Vp-p |
| PO OUTPUT PARAMETERS (ENHANCED OVER-EAR HEADPHONE MODE) | |
| OUTPUT POWER | ≥1.4W(16Ω / THD+N<1%) ≥1.1W(32Ω /THD+N<1%) ≥126mW(300Ω / THD+N<1%) |
| NOISE FLOOR | ≤3.5μV(dbA) |
| FREQUENCY RESPONSE | 5Hz~80kHz(-3dB) |
| OUTPUT IMPEDANCE | ≤1Ω(32Ω) |
| CROSSTALK | ≥75dB(1kHz/32Ω) |
| THD+N | ≤0.0009%(1kHz/32Ω) |
| SNR | ≥122dB(dbA) |
| PEAK OUTPUT VOLTAGE | 16.9 Vp-p |
| LO OUTPUT PARAMETERS | |
| NOISE FLOOR | ≤2μV(dbA) |
| FREQUENCY RESPONSE | 5Hz~80kHz(-3dB) |
| CROSSTALK | ≥103dB(1kHz/10kΩ) |
| THD+N | ≤0.0006%(1kHz/10kΩ) |
| SNR | ≥120dB(dbA) |
| LO OUTPUT LEVEL | 1.9V(1kHz/10kΩ) |
| PO BALANCED OUTPUT PARAMETERS(OVER-EAR HEADPHONE MODE) | |
| OUTPUT POWER | ≥1.5W(16Ω / THD+N<1%) ≥3W(32Ω /THD+N<1%) ≥250mW(300Ω /THD+N<1%) |
| NOISE FLOOR | ≤7μV(dbA) |
| FREQUENCY RESPONSE | 5Hz~80kHz(-3dB) |
| OUTPUT IMPEDANCE | ≤2Ω(32Ω) |
| CROSSTALK | ≤0.0007%(1kHz/32Ω) |
| THD+N | ≥108dB(1kHz/32Ω) |
| SNR | ≥121dB(dbA) |
| PEAK OUTPUT VOLTAGE | 19.7 Vp-p |
| PO BALANCED OUTPUT PARAMETERS(ENHANCED OVER-EAR HEADPHONE MODE) | |
| OUTPUT POWER | ≥1.5W(16Ω / THD+N<1%) ≥3W(32Ω /THD+N<1%) ≥500mW(300Ω /THD+N<1%) |
| NOISE FLOOR | ≤7μV(dbA) |
| FREQUENCY RESPONSE | 5Hz~80kHz(-3dB) |
| OUTPUT IMPEDANCE | ≤2Ω(32Ω) |
| CROSSTALK | ≤0.0009%(1kHz/32Ω) |
| THD+N | ≥108dB(1kHz/32Ω) |
| SNR | ≥121dB(dbA) |
| PEAK OUTPUT VOLTAGE | 27.7 Vp-p |
| LO BALANCED OUTPUT PARAMETERS(dbA) | |
| NOISE FLOOR | ≤3μV(dbA) |
| FREQUENCY RESPONSE | 5Hz~80kHz(-3dB) |
| CROSSTALK | ≥105dB(1kHz/10kΩ) |
| THD+N | ≤0.0006%(1kHz/10kΩ) |
| SNR | ≥122dB(dbA) |
| LO OUTPUT LEVEL | 3.9V(1kHz/10kΩ) |
| LOSSLESS | DSD:DSD64/128/256 (“.iso”,“.dsf”,“.dff”),DST iSO DXD:352.8kHz/24bit APE FAST/High/Normal:384kHz/24bit(MAX) APE Extra High:192kHz/24bit(MAX) APE Insane:96kHz/24bit(MAX) Apple Lossless:384kHz/32bit(MAX) AIFF:384kHz/32bit(MAX) FLAC:384kHz/32bit(MAX) WAV:384kHz/32bit(MAX) WMA LOSSLESS:96kHz/24bit(MAX) |
| LOSSY | MP3,OGG,WMA,AAC, etc. |
| BOX CONTENTS | 1. FiiO M17 Digital Audio Player |
| 2. External DC Adapter | |
| 3. USB 3.0 Data and Power cable | |
| 4. Cooling stand with fan | |
| 5. Leather Case | |
| 6. PET Screen Protector with Oleophobic layer | |
| 7. Micro-SD card with ejector pin | |
| 8. Aluminum dust plug |
FAQS
Warranty & Media Reviews
1 Year Warranty
Don’t sweat it, this FiiO M17 comes with a 1 year warranty from FiiO that covers manufacturing defects. All products featured on Headphone Zone are backed by an original manufacturer’s warranty.
Read more about FiiO’s warranty in India.

Life Style
VGP 2022 Lifestyle
Nov, 2021







































Reviews
There are no reviews yet.
